Key Considerations Public Cloud Private Cloud Hybrid Cloud
Infrastructure Multi-Tenant Virtualized Dedicate, single-tenant Combination of both
Compute Resource Shared virtual machines (VMs), containers, and serverless options (AWS EC2, GKE, AKS) Dedicated VMs, Kubernetes clusters, and bare metal servers Workloads dynamically placed in public or private cloud
Storage Architecture Object storage (S3, Blob, GCS), Block Storage (EBS, SSD), File Storage (NFS, EFS, Azure Files) On-prem NVMe SSDs, SAN, NAS, object storage (MinIO, Ceph) Hybrid storage with tiering between on-prem and cloud
Networking Virtual Private Cloud (VPC), SDN-based (AWS VPC, Azure VNet, GCP VPC) Physical network with VLANs, BGP, MPLS, and private SDN Hybrid network using VPN, SD-WAN, or Direct Connect
Latency Higher due to internet-based access Low due to on-premises infrastructure Low-to-medium, depending on cloud interconnects
Load Balancing Cloud-native load balancers (ELB, ALB, NLB, GCLB) Hardware-based (F5, Citrix ADC) or software (NGINX, HAProxy) Hybrid with global traffic routing (AWS Route 53, Azure Traffic Manager)
Containerization & Orchestration Kubernetes (EKS, AKS, GKE), Docker, Fargate (serverless containers) Self-hosted Kubernetes (K3s, OpenShift, Rancher) Hybrid Kubernetes (Anthos, Azure Arc, AWS Outposts)
Serverless Computing Fully managed (AWS Lambda, Azure Functions, Google Cloud Functions) Limited to private function execution environments Hybrid serverless via API gateways and edge computing
Edge Computing Supported via cloud edge services (AWS Wavelength, Azure Edge Zones) Not inherently available; requires custom setup Edge workloads can run locally while processing in the cloud
Security Model Shared Responsibility Model (IAM, WAF, Shield, DDoS protection) Full control over security policies, firewalls, and access control A combination of both hybrid IAM and security policies is required
Identity & Access Management (IAM) Cloud IAM solutions (AWS IAM, Azure AD, Google Cloud IAM) On-prem directory services (Active Directory, LDAP, Okta) Hybrid identity federation (AWS SSO, Azure AD B2C)
Encryption & Key Management Cloud KMS (AWS KMS, Azure Key Vault, Google Cloud KMS) Hardware Security Modules (HSM), self-hosted KMS (Vault by HashiCorp) Hybrid KMS integration for unified encryption
Networking Protocols HTTPS, TLS, QUIC, IPv6, Anycast MPLS, BGP, IPv4, custom routing protocols Combination of public and private networking protocols
Data Residency & Compliance Depends on the provider's data centers (multi-region) On-premises storage allows full control Data partitioning based on compliance needs
Disaster Recovery (DR) Cloud-based DRaaS (AWS Backup, Azure Site Recovery) On-premises DR solutions, cold/hot backup sites Hybrid DR (cross-replication between cloud and on-prem)
